WALL TYPE

> PA > WALL TYPE

PRODUCT FEATURES: - Rated output: 60/120/240/360/480/600 Hz, with a duty
cycle of less than 1%. High reliability, Digital amplifier
circuitry (70V/100V selectable).
- Connected to a fire alarm panel, automatically transmits
fire evacuation announcements to the fire floor and the floor
immediately above. Up to four underground floors can be
configured, P-type and R-type receivers are compatible,
R-type fire data protocol: 12 bytes, 9600bps.
- Remote broadcasting is possible with the DMS-8RM
remote amplifier.
- Various functions, including contact, DC, SIG, and 100V,
ensure compatibility with existing analog remote devices.
- Broadcasting functions for underground floors, individual
(zone-specific), and all-selection.
- 4-tone chime and built-in microphone for general
announcements.
- Buildings with 16 or 32 floors or more can use four
16-channel/32-channel option cards for serial processing.
(Option cards sold separately: EWA-16M/32M)
- Program Timer function with the addition of a TIMER module
(Optional card EWA-16PT/32PT) - USB, SD card, and external
input output with the addition of an MP3 module
- Emergency operation function with built-in battery
